Advantages and shortages of the ball grinding mill

CFTC introduces the advantages and shortages of the ball grinding mill briefly in this article. The ball grinding mill mainly has six advantages and four shortages. Since ball grinding mill has such more advantages, it has been widely used in many industries.

1. Advantages

1.1 The ball grinding mill can process various materials and can work continuously. Besides it also has high capacity which can meet the needs of large production scale.
1.2 High crushing ratio about more than 300. Besides, it is easy to adjust product fineness.
1.3 The ball grinding mill can work at different environment. It is divided into wet and dry, two types. It also can integrate dry grinding processes simultaneously. 1.4 The ball grinding mill with reliable operation can work continuously for a long time.
1.5 Maintenance management is simple and easy.
1.6 There are good sealing devices to prevent dust flying.

2. Disadvantages

2.1 Low efficiency: power used to grinding is 2/3 of the whole plant in producing cement. According to statistics, the power consumption for each ton of cement produced is not less than 70 kWh, but the effective utilization of this part of electricity is very low. According to analysis, the power consumption of the input power for grinding materials (doing useful work) accounts for only a small part, about 5% to 7%, and most of the electrical energy is consumed in other aspects, mainly converted into thermal and acoustic energy and disappears, which is a big waste.
2.2 Heavy and bulky machine: the total weight of large ball mills can reach several hundred tons or more, so the one-time investment is bound to be large. 2.3 Expensive configuration: Due to the low rotation speed of the cylinder (15 to 25 revolutions per minute), if it is driven by an ordinary motor, it needs to be equipped with an expensive reduction gear.
2.4 High production cost: while the grinding body impacts and grinds the material, it will also be abraded and stripped, and the liner and other parts in the cylinder are also abraded and stripped. Therefore, in the entire cement production process, the amount of iron plates consumed by the pulverization operation (raw material preparation, cement grinding) is very large. According to analysis, about 1 kg of steel is consumed per ton of cement produced.
In addition, CFTC also reminds you that the ball mill is a 24-hour continuous working device. During the period, if there is no running problem, do not stop the machine to avoid wasting more power and time, because the ball mill consumes too much power at startup.
